18
6. SD-CARD slot
Insert the SD Card into the slot
7. Display
Displays information about the MP3 player
8. CONTROL
Navigation command.
After inserting input storage media (USB or SD card) containing music tracks in MP3, browse songs by turning
the control to the right or to the left.Once you have found the song you want to play, press the button to start
playback, at a second press of the button, the playback will pause, press again to resume. The display (Fig.1,
ref.7) will show the song title and the progress of the playback.
Note: When you switch ON the device without inserting a USB drive or SD-CARD, the display will show a
counter that advances, indicating the time of use of the device.
After playing the song chosen, the MP3 player will automatically switch to the next track. When the last track
has been played, the device will remain in stand-by mode.
Keeping the Control wheel rotated to the right or to the left, you will go respectively to increase or decrease the
volume of your MP3 player (the display (fig. 1, ref.7) shows a level between 00 and 15)
9. MP3 VOL
MP3 Player Volume
10. W MIC VOL
Turn the control clockwise to turn ON the radio or increase the playback volume of the signal from the wireless
transmitter.
Turn the control anti-clockwise to turn OFF the radio receiver or decrease the playback volume of the signal
from the wireless transmitter.
11. RF Indicator
When the indicator is ON, the microphone is operative
12. MIC IN
Microphone input – Mono Jack 6.3 mm
13. MIC VOL
Adjusts the level of the respective microphone input
14. LIN IN
Line input – Mono Jack 6.3 mm
15. LIN VOL
Adjusts the level of the respective input line
16. DC IN 18V
18V DC power supply Input.
Connect this input to the supplied AC/DC 100-240Vac / 20Vdc
17. % BAT
When the battery is low, the red LED “25%” will be ON, arrange as soon as possible to recharge the battery
18. Stand flange
M6 thread for dedicated optional pole mounting SPSK105BKF5
19. Handle
20. Shoulder strap clip
