12
Thank you for choosing one of Proel products, and for your confidence towards our brand, synonymous of
professionalism, accuracy, high quality and reliability. All our products are CE approved and designed for
continuous use in professional installation systems.
2. DESCRIPTION
PROEL TOUR wireless kit is the ideal system to allow a comfortable guided tour in museums or in ambient
of tourism interest. Using such system the group of persons involved in the guided tour can receive full
audio information. TOUR Proel kit is composed by 2 parts: a pocket receiver RXTOUR and a pocket
transmitter TXTOUR ( available for sales separately).
TOUR Proel system can operate on 3 frequencies range to be selected amongst the interval band 175 ÷
176MHz (VHF) – Quartz technology. In the same area 3 transmitters set on different frequencies can
operate contemporaneously (each with a different frequency ) and un an indefinite number of receivers.
The receiver RXTOUR is of great levels of performance and characteristics because designed accordingly
to advanced technologies to ensure not only a high level of quality but also wide outdoor and indoor
application and use.
RXTOUR is earphone and volume control purposes equipped to allow an independent listening and volume
intensity of signal received. RXTOUR is 3 positions selector and led provided for respectively signal
received synchronization and battery charge level visualization.
RXTOUR is supplied with a shock resistant and anti-scratch plastic case and antenna. Operating with two
1,5 V AAA batteries – Maximum autonomy over than 8 hours continuous use.
The transmitter is as follows equipped: led for battery charge level indication, Electret cardioide condenser
microphone with 3 sensibility positions control and rotating gain control.
TXTOUR is supplied with a shock resistant anti-scratch plastic case and antenna. Operating with two 1,5 V
AAA batteries- Maximum autonomy : over than 8 hours in continuous use.
Both the TOUR receiver and transmitter are supplied with a practical clip to allow to belt or pocket hooking
for a comfortable use.
3. RXTOUR RECEIVER -FUNCTIONS AND CONTROL
fig.1
1 Power on switch
2 Signal -received by earphone- volume control
3 Led for transmitter signal presence indication
Led lights when the transmitter is in operating mode
