5019 612 10243
Programme
Temperature
(°C)
Load
(kg)
Water
(l)
Energy
without “Rapid”
(kWh)
Approx. Programme Duration (hrs : min)
without “Rapid” with “Rapid”
Cotton 95 5.0 50* 1.70 2:05 –
Cotton** 60 5.0 47 0.89 2:45 2:10
Cotton** 60 2.5 32 0.68 2:10 ***
Cotton 40 5.0 47 0.65 2:00 1:45
Cotton** 40 2.5 32 0.52 1:45 ***
Synthetics 60 3.0 50* 0.90 2:05 1:14
Synthetics 40 3.0 40 0.50 1:50 0:59
Delicates 40 1.5 50 0.55 0:45 –
Daily load 40 3.0 40 0.45 1:00 –
Quick wash 15´ 30 3.0 30 0.15 0:15 –
Wool 40 1.0 55 0.55 0:45 –
Handwash 40 1.0 40 0.40 0:35 –
CONSUMPTION DATA
1. Load the machine, close the drum doors and check
that they are properly locked.
2. Add detergent and additives into the dispenser to
no more than the “MAX” level mark, as follows:
• Programme with pre and main wash
• Main wash programme without prewash
• Fabric softeners and conditioners
• Stain remover agents
• Anti-scale agents (if necessary)
3. Close the lid.
4. Turn the programme selector to the desired
programme and temperature. The lamp next to the
“Start/Pause” button flashes. The indication lamp
of the predefined spin speed lights up.
PREPARATION OF THE WASH CYCLE
“DOOR OPEN” INDICATION
Before starting and after end of a programme, the lamp
lights to show the the lid can be opened. As long as a
wash programme is running, the lid remains locked and
must on no account be forced open. In case you have
an urgent need to open it during a running programme,
refer to “Cancel (Reset) a running programme before
the end”.
PROGRAMME START
Open the tap and press the “Start/Pause” button.
The indication lamp next to the “Start/Pause” button
lights up. The programme sequence indicator shows
the current programme phase, running from left to right
through Wash, Rinse, Spin/Drain. When the programme
phrase is finised, the corresponding indication goes out.
• Note: If there is a power interruption or if the
appliance is disconnected during the cycle, the
programme will run again from the point where it
was interrupted.
PROGRAMME END
• All the lights of the programme sequence indicator
are off, and the “Door open” indication lights up.
1. Turn the programme selector to the “Off/O”
position.
2. Close the water tap.
3. Open lid and drum and unload the machine.
4. Leave the lid open for some time to allow the
interior of the machine to dry.
CHANGE PROGRAMME AND/OR OPTIONS
AFTER PROGRAMME START
1. Press the “Start/Pause” button to pause the
programme. The light flashes.
2. Select the new programme, any options and another
spin speed if you want.
3. Press the “Start/Pause” button again. The new
programme continues at the same position where
the previous programme was interrupted. Do not
add detergent for this programme.
CANCEL (RESET) A RUNNING PROGRAMME
BEFORE THE END
The “Reset” button cancels a programme before the
end. Press the “Reset” button for at least 3 seconds.
Any existing water is drained out before the door can be
opened.
SELECT THE DESIRED OPTION(S)
Selecting or deselecting an option can be done at
any time during the programme. The option will be
applied as long as the corresponding programme
phase has not been executed yet.
“Rinse hold” button
• The laundry remains in the last rinse water without
progressing to the final spin cycle to avoid creasing
and prevent colours from changing.
• This option is particularly recommended for the
“Synthetics”, “Daily load” and “Delicates”
programmes.
• It is useful if you want to postpone spinning to a later
time, or if you want to drain out only.
• If you select “Rinse Hold”, do not leave items to
soak for too long.
• As soon as the appliance stops in the rinse hold, the
“Rinse hold” lamp of the sequence indicator lights up
and the lamp next to the “Start/Pause” button flashes.
Terminate the “Rinse hold” option:
• Press the “Start/Pause” button; the programme
will terminate automatically with the final spin cycle
for the present wash programme.
• If you do not wish to spin the clothes, turn the
programme selector knob to the “Drain”
programme and press the “Start/Pause” button.
“Prewash” button
• Only for heavily soiled loads (for example sand,
granular dirt). Increases the cycle time by
approximately 20 min.
“Rapid” button
• Enables quicker washing by shortening the
programme duration.
• Recommendable for small loads or only lightly soiled
laundry.
“Variable spin” button
• Every programme has a predefined spin speed.
• Press the button to set another spin speed.
• If spin speed “0” is selected, the final spinning is
cancelled but intermediate spin peaks remain during
the rinse. The water is drained out only.
Consumption values were measured in normalized conditions in compliance with standard IEC/EN 60 456. Consumption data in the home may vary with
respect to the values in the table in relation to the water supply pressure and temperature, the load and the type of wash.Water and energy consumption refer
to the default setting of the programmes; selecting special options or modifying spin speed or temperature will change the consumption data.
The programme duration may differ from the values indicated above as it depends on the operation conditions applicable at that time (see also
“Troubleshooting Guide” in your Instructions for Use).
* To reduce the water temperature, some cold water is added at the end of the main wash cycle, before the pump drains the water out.
** Reference Programmes for Energy Label.
*** Automatic adaption of programme duration after detection of wash load.
FAILURE INDICATIONS
In case of any failures or irregularities, consult the
“Troubleshooting Guide” in your Instructions for Use.
“Service”
Lighting up of the “Service” indication can be caused
by a fault in an electrical component. Refer to the
“Troubleshooting Guide” in your “Instructions for Use”;
if the fault persists, contact our After Sales Service.
“Water tap closed”
The appliance has no or insufficient water supply. Open
the water tap: if the indications still lights up, refer to the
“Troubleshooting Guide” in the Instructions for Use.
“Clean pump”
Waste water is not pumped out. Check whether the
drain hose is kinked or the filter must be cleaned: in the
latter case refer to the Instructions for Use (“Removing
the Filter”).
