20

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

4.

Remove the

Cage Nuts

from the

Depth Adjustment Rails

by applying pressure to both sides of the

Cage Nut

.

- or -

Use a

Cage Nut Wrench

to remove the

Cage Nuts

from the

Depth Adjustment Rails

.

5.

Once you have determined the mounting depth reinstall the

Cage Nuts

into the

Depth Adjustment Rails

.

6.

Slide the

Mounting Rail

along the

Depth Adjustment Rail

aligning it with the

Cage Nuts

inserted in step 5.

Notes:

The distance between each of the

Mounting Rail

Adjustment Holes

is .827” (21 mm).

7.

Insert the

M6 Screws

through the

Mounting Rail

and into

the

Cage Nuts

.

8.

Use a

Phillips Head Screwdriver

to tighten the

M6 Screws

.
