6 GB/MT ®
rose Arch
Q Introduction
Familiarise yourself with the product prior to assembly. Carefully
read the following assembly instructions and safety tips. Only use
the product as instructed and only for the indicated field of appli-
cation. Keep instructions in a safe place. Submit all documents to a third party
if distributing the product.
Q Intended Application
This product is indended as a climbing aid for plants. Any use other than
previously mentioned or any product modification is prohibited and can lead
to injuries and / or product damage. The manufacturer is not liable for any
damages caused by any use other than for the intended purpose. The product
is not intended for commercial use.
Q Description of parts
1 Intermediate stanchion
2 Ground anchor with bolt
3 Ground anchor without bolt
4 Connection piece
5 Bend
6 Screw (approx. 17 x ø 5.7 mm)
7 Peg
8 Mounting bracket
9 Screw (approx. 12 x ø 4.6 mm)
10 Nut
Q Dimensions and Material
Material: Metal
Dimensions: approx. 133 x 260 x 38.5 cm (W x H x D)
Q Scope of Delivery
Check the delivery for completeness and condition of the product immediately
after opening and ensure all parts are included. Do not assemble product if
delivery is incomplete.
11 intermediate stanchions (approx. 35.5 cm)
2 ground anchors with bolt (approx. 49.2 cm)
2 ground anchors without bolt (approx. 49.2 cm)
12 connection pieces (approx. 51.3 cm)
8 bends (approx. 55.5 cm)
23 screws (approx. 17 x ø 5.7 mm)
4 pegs
4 mounting brackets
8 screws (approx. 12 x ø 4.6 mm)
8 nuts
1 assembly instructions
Safety instructions
J WArnInG! DAnGer tO LIFe AnD rISk OF
AccIDentS FOr InFAntS AnD chILDren! Never
leave children unattended with the packaging material. Risk
of suffocation keep children out of reach.
J cAUtIOn! rISk OF InJUrY! Ensure that all parts are undamaged
and have been assembled appropriately. Risk of injury exists if assembeled
incorrectly. Damaged parts can effect safety and function.
J cAUtIOn! Do not leave children unattended! The rose arch is not a toy
or climbing equipment! Ensure that persons, in particular children do not
climb onto the rose arch and do not use it as a leaning post. The rose
arch may overbalance and tip over.
J Ensure that the rose arch is only assembled by skilful adults.
J Ensure that you place the rose arch on a solid and even surface. Do not
place the rose arch on sand. Non-observance may lead to a risk of injury
and / or product damage.
J Ensure to secure the rose arch firmly into the ground. Check the ground
anchoring and tighten the screws
6 on a regular basis. If required,
secure the product against tipping over. The rose arch may overbalance
and tip over.
J Do not hang any items from the rose arch. Non-observance may lead to
risk of injury and / or product damage.
Q Assembly
Proceed as follows:
1. When starting to assemble, arrange 6 connection pieces
4 , 4 bends 5 ,
one ground anchor with bolt 2 and one ground anchor without bolt 3
into an arch shape (see Fig. A). Subsequently join the parts together.
note: Ensure that the underground is solid and even.
2. Attach the intermediate stanchions 1 with 11 screws 6 with parts in
Fig. A (see Fig. B). Align holes when connecting 2 , 3 , 4 , 5 .
note: Do not tighten screws 6 completely.
3. Arrange 6 connection pieces 4 , 4 bends 5 , one ground anchor with
bolt 2 and one ground anchor without bolt 3 for the second arch. Sub-
sequently join the parts together (see Fig. A).
4. Attach the second arch with 11 screws 6 to the intermediate stanchions 1
(see Fig. C).
5. Retighten all screw connections.
6. Press the rose arch firmly into the ground in order to ensure a safe stand-
ing position. Ensure that the ground anchors 2 , 3 reach into the ground
by at least 20 cm and the width of rose arch is approx. 133 cm.
7. Enhance the stability of the product by fixing it to the ground with the
supplied pegs 7 . To do so attach the mounting brackets 8 to the ground
anchors 2 , 3 using the screws 9 and nuts 10 (see Fig. D). Then push
the pegs 7 through the openings in the mounting brackets 8 and into
the soil.
Q cleaning and care
j To clean use a damp, lint-free cloth.
Q Disposal
The packaging is made entirely of recyclable materials, which you
may dispose of at local recycling facilities.
Contact your local refuse disposal authority for more details of how to dispose
of your worn-out product.
Product Description:
Rose Arch
Model No.: Z6735A
Version: 10 / 2010
