12 GB/MT
Sunlounger
Intended use
This product is intended to be used for recreational
and camping purposes (outdoor area) only. The
product is not intended for commercial use.
Safety instructions
DANGER TO
LIFE AND RISK OF ACCIDENT
TO INFANTS AND CHILDREN!
Never leave children unattended with the pack-
aging material. There is a danger of suffocation.
CAUTION! RISK OF INJURY! Make sure
that no parts are damaged. Damaged parts
could adversely affect safety and proper function.
CAUTION! DANGER OF INJURY DUE
TO CRUSHING! Make sure you do not trap
your fingers when opening or closing the prod-
uct. A moment of inattention may result in injury
due to crushing.
Make sure that this product is standing on a
solid, level surface.
CAUTION! Do not allow children to use the
product unsupervised! This product is not a
climbing frame or a toy! Make sure that nobody,
in particular a child, sits on the top or bottom
end of the product.
This lounger is not suitable for the transportation
of persons!
Assembly
Assembling foot frame
Note: Leave the lounger folded together to make
the assembly of the foot frame easier.
Note: To assemble, you need the enclosed assem-
bly tool
1 or a crosshead screwdriver.
The screws (I) are already pre-fitted at the lower
end of the main frame when delivered. Loosen
the screws completely from the connecting (II)
rod using the enclosed assembly tool and put
them to one side (see Fig. A).
Pull out the inside rod approx. 2 cm. Make sure
that the holes of the inner rod are in the same
position as the holes of the foot frame. Now
insert the foot frame (III) into the main frame (IV)
(see Fig. B).
Now fasten the connecting rod to the foot
frame using the screw (I) and assembly tool
(see Fig. C, D).
Assembling wheels
Unscrew the domed nut and washer from the
joint (VII) (see Fig. E).
Remove the pin with thread (X) from the joint
(VII). Now reinsert the pin into the joint and
make sure that the threaded hole of the pin is
pointing upwards. Insert the pin until the
threaded hole and the hole of the axle rod lie
on top of each other (see Fig. E – G).
Now screw the locking screw 2 into the
threaded holes provided on either side. Push
the wheel
9 onto the joint and fasten this with
the washer and domed nut. You will require the
assembly tool for this (see Fig. H, I).
Repeat this procedure to assemble the other
wheel.
Assembling sunshade
Push the screws 7 through the frame from the
inside to the outside (XII). Attach the sleeves 3
and fasten the oval rod 8 using the large
locking screw 5 (see Fig. J, K).
Repeat this procedure at the upper end of the sun-
shade. Here, however, use the small screws 6
and small locking screws 4 .
Using as transport aid
The lounger can also be used as a transport aid
(see Fig. M, N).
