Remove spent batteries / rechargeable batteries immedi-
ately from the device. There is an increased danger of
leaks!
Always replace all the batteries / rechargeable batteries
at the same time.
Batteries / rechargeable batteries must not be disposed
of in the normal domestic waste!
Every consumer is legally obliged to dispose of batteries /
rechargeable batteries in the proper manner!
CAUTION! EXPLOSION HAZARD!
Keep batteries / rechargeable batteries away
from children. Do not throw batteries / recharge-
able batteries into a fire.Never short-circuit them or take
them apart.
If the above instructions are not complied with, the batter-
ies may discharge themselves beyond their end voltage.
There is then a danger of leaking.
If the batteries / rechargeable batteries have leaked inside
your appliance, you should remove them immediately in
order to prevent damage to the appliance!
Avoid contact with the skin, eyes and mucous membranes
if fluid is leaking from the batteries / rechargeable batter-
ies. If you come into contact with corrosive battery fluids,
flush the affected area thoroughly with clean water and
seek medical advice immediately.
Before initial use
Inserting the batteries /
rechargeable batteries
The lights are battery or rechargeable battery operated.
Note: Only use alkaline batteries or comparable recharge-
able batteries with 1.2 V .
Slide open the battery compartment cover 6 , 15 towards
the back and remove it from the lamp casing 2 , 14 .
For the front light, pull the battery compartment 7 out
of the light.
Insert the batteries / rechargeable batteries into the battery
compartment 7 , 16 . Check the polarity of the battery
during insertion! This is shown inside the battery com-
partment. Use only batteries / rechargeable batteries of
the specified type (see “Technical Data”).
For the front light, replace the battery compartment 7 .
Slide the battery compartment cover 6 , 15 back onto
the lamp casing 2 , 14 .
Note: Charger and rechargeable batteries are not included.
Only use a charger from a specialist retailer, which is suitable
for charging 4 rechargeable batteries each of 1.2 V. The
charger requires a 3.5 mm terminal. If necessary consult a
specialist in order to avoid damage and danger.
Note: The charging socket 8 for the charger is located
on the front light.
CAUTION! EXPLOSION HAZARD! The
batteries supplied must never be recharged.
Only rechargeable batteries can be recharged.
Note: A battery indicator is located in the On / Off
button 1 and 10 the front and rear lights. This lights up
red when the batteries need to be replaced, or the
rechargeable batteries need to be recharged.
Mounting the lights
Front light:
Release the locking screw 4 from the mounting ring 5 .
Place the mounting ring 5 around the handlebar.
Tighten the locking screw 4 to secure it in the mounting
ring 5 .
Note: With the aid of the rubber seals 9 in the mount-
ing ring 5 , adjust the bracket 3 to fit precisely to your
handlebar.
Slide the lamp casing 2 onto the bracket 3 .
Rear light:
Place the mounting ring 11 around the seat post.
Slide the lamp casing 14 onto the bracket 13 .
Loosen the locking screw 12 , but do not remove it com-
pletely to be able to adjust the beam angle of the rear
light.
Retighten the locking screw 12 .
Operation
Switch on the lights by pressing the On / Off button 1 , 10 .
Press once to activate the Power Mode. Press twice to
activate the Eco Mode.
Switch the lights on again by pressing the On / Off
button 1 , 10 again, either once or twice.
Note: The front light has two brightness settings:
Power mode with 30 lux: Press the On / Off button 1
once for cycling in dark, unlit areas.
Eco mode with 15 lux: Press the On / Off button 1 a
second time for cycling in lit areas.
Note: If the LEDs fail then the whole light must be
replaced.
Cleaning
Do not under any circumstances use corrosive or abrasive
cleaning agents. Otherwise damage to the product can
result.
Use a slightly damp, fluff-free cloth for cleaning the product.
Do not immerse the lamp in water!
Disposal
The packaging is made entirely of recyclable
materials that you can dispose of at your local
recycling facilities.
Contact your local waste disposal authority for more details
on how to dispose of the product when it is no longer needed.
To help protect the environment, please dispose
the product properly, and not in the household
waste, when it has reached the end of its useful
life. Contact your municipal authorities for infor-
mation regarding collection points and their
opening hours.
Faulty or used batteries / rechargeable batteries must be
recycled in accordance with Directive 2006 / 66 / EC.
Return batteries / rechargeable batteries and / or the appli-
ance using the recycling facilities provided.
Pb
Environmental damage through
incorrect disposal of the batteries /
rechargeable batteries!
Never dispose of batteries / rechargeable batteries in your
household waste. They may contain toxic heavy metals and
are subject to hazardous waste regulations. The chemical
symbols of the heavy metals are: Cd = cadmium, Hg = mercury,
Pb = lead. Therefore, dispose of used batteries / rechargeable
batteries through your local collection site.
Product description:
LED Bike Light Set
Art. No.:
97331-71
Model No.: Front light: XC-116 / L-Switch 30 / 15
Rear light: XC-117 / X-LED
Type: L-Switch, X-LED
IAN 89265
Inter-Union Technohandel gmbH
Klaus-von-Klitzing-Str. 2
D-76829 Landau / Pfalz
[email protected]
Tel: +49 (0) 63 41 28 4-332
Versione delle informazioni
Last Information Update: 04 / 2013
Ident.-No.: 97331042013-IT
