10
Thank you for choosing a Proel product and for trusting our brand, synonymous with professional competence,
accuracy, high quality and reliability. All our products comply with CE regulations governing use of pubblic address
systems.
2. DESCRIPTION
The module consists of two independently operating sound sources which can be used simultaneously, each of them
with a dedicated RCA stereo output. A third combined audio RCA output is also available.
The CD player can read audio tracks and MP3 files from CD/CD-R/CD-RW, and its features include power-assisted
CD insert/eject and USB port to play MP3 files on Flash Pen Drives.
The FM Tuner features automatic frequency selection and 20 memory presets.
The unit can be mounted on a standard 19” rack.
Main Functions:
• CD/MP3/CD-R and CD-RW player.
• USB port to play MP3 files stored on pen drives.
• FM Radio Tuner
• Separate level controls for the three outputs (CD/MP3 – FM Tuner - Mixed)
• Back-lit
LCD displays.
• IR remote control included.
• Designed to be mounted on standard 19” rack -.1 modular unit.
3. FRONT PANEL CONTROLS AND FUNCTIONS
fig.1
52. USB mode
53. CD mode
54. Eject
55. Track/Station preset button 1
56. Track/Station preset button 2
57. Track/Station preset button 3
58. Track/Station preset button 4
59. Track/Station preset button 5
60. Down Key
61. Up Key
62. Track/Station preset button 6
63. Track/Station preset button 7
64. Track/Station preset button 8
65. Track/Station preset button 9
66. Track/Station preset button 10
67. Memory
68. Power 35. On / Off Switch
36. CD Display
37. Tuner Display
38. USB Port
39. CD Housing
40. IR Socket
41. Folder-Dow
42. Folder-Up
43. Down/Rev
44. Up Cue
45. Stop
46. Play/Pause
47. Power
48. Program
49. Electronic shock protection
50. Find
51. Play mode
