3
INDEX
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . 3
FREQUENCY RESPONSE . . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONS AND FLYING POINTS . . . . . . . . . . . . . 4
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CONTROL PANEL (FIG.1/2) . . . . . . . . . . . . . . . . . . . 6
FLASH5A CONNECTIONS (FIG.3) . . . . . . . . . . . . . . 6
CONFIGURATIONS (FIG.4/5) . . . . . . . . . . . . . . . . . . 7
SAFETY AND PRECAUTIONS . . . . . . . . . . . . . . . . . . 8
IN CASE OF FAULT . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . 8
CE CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PACKAGING, SHIPPING AND COMPLAINT . . . . . . . 9
WARRANTY AND PRODUCTS RETURN . . . . . . . . . . 9
INSTALLATION AND DISCLAIMER . . . . . . . . . . . . . . 9
POWER SUPPLY AND MAINTENANCE . . . . . . . . . . 9
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . 10
INSTRUCTIONS (FIG. 1 / 2 / 3) . . . . . . . . . . . . . . . 10
INDICE
SPECIFICHE TECNICHE . . . . . . . . . . . . . . . . . . . . . . 3
RISPOSTA IN FREQUENZA . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONI E PUNTI DI SOSPENSIONE. . . . . . . . . 4
ACCESSORI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PANNELLO DI CONTROLLO (FIG.1/2) . . . . . . . . . . . 6
FLASH5A CONNESSIONI (FIG.3) . . . . . . . . . . . . . . . 6
CONFIGURAZIONI (FIG.4/5) . . . . . . . . . . . . . . . . . . 7
AVVERTENZE PER LA SICUREZZA . . . . . . . . . . . . . 12
IN CASO DI GUASTO . . . . . . . . . . . . . . . . . . . . . . . 12
PROBLEMATICHE COMUNI . . . . . . . . . . . . . . . . . . 12
CONFORMITÀ CE . . . . . . . . . . . . . . . . . . . . . . . . . . 13
IMBALLAGGIO, TRASPORTO E RECLAMI . . . . . . . 13
GARANZIE E RESI . . . . . . . . . . . . . . . . . . . . . . . . . 13
INSTALLAZIONE E LIMITAZIONI D’USO . . . . . . . . . 13
ALIMENTAZIONE E MANUTENZIONE . . . . . . . . . . 13
INFORMAZIONI GENERALI . . . . . . . . . . . . . . . . . . 14
ISTRUZIONI (FIG. 1 / 2 / 3) . . . . . . . . . . . . . . . . . . 14
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
MODEL FLASH5AV2 FLASH5PV2
System type 2-way vented enclosure 2-way vented enclosure
High Frequency Device 1'' so dome tweeter on ellip cal waveguide 1'' so dome tweeter on ellip cal waveguide
Low Frequency Device 5'' woofer 5'' woofer
Angular coverage 90° H x 60° V 90° H x 60° V
Nominal Impedance - 16 ohm
Input Power Ra ng (con nuos) - 80 W
Input Power Ra ng (peak) - 160 W
Amplifi er Peak Power 200 W
HF Amplifi er Con nuous Power 20 W Class AB -
LF Amplifi er Con nuous Power 80 W Class D -
Frequency response 70 Hz - 20 kHz 80 Hz - 20 kHz
Sensi vity - 91 dB @ 1 W/1 m
Max SPL 114 dB 113 dB
Connectors RCA / XLR / JACK Push terminals
Controls Level, gnd li , NEAR FIELD / MID FIELD -
Crossover Frequency 3000 Hz 3000 Hz
Input Impedance (XLR / JACK) 30 kohm balanced / 15 kohm unbalanced
Input Sensi vity (XLR / JACK) 0 dBu / 0.775 V
Input Impedance (RCA) 10 kohm unbalanced
Input Sensi vity (RCA) -10 dBu / 0.245 V
Monitor taper 42° 42°
Flying System 3 x M6 - top, bo om 3 x M6 - top, bo om
Construc on Polypropylene Polypropylene
Cabinet Colour Black Black or White
Weight 3.6 kg (7.9 lb) 2.5 kg (5.5 lb)
Dimensions (W x H x D) 175 x 265 x 176.5 mm 175 x 265 x 176.5 mm
Power Supply 230 VAC or 120 VAC - 50/60 Hz -
Consump on 60 W -
