3.4 Setup Address: Internal Section
(cont.)
Category Parameter
Address MSB/LSB (HEX)
Byte Value(HEX)
MAIN SUB1 SUB2 SUB3
6. Control Damper Pedal On/Off 01/2C 02/50 03/74 05/18 1 00,01 (Off , On)
Damper Pedal Assign 00/2E 1 00-11*
Soft Pedal Adjust 00/70 02/14 03/38 04/5C 1 01-0A
Damper Mode 01/2B 02/4F 03/73 05/17 1 00,01 (Normal, Hold)
PitchBend Wheel On/Off 01/33 02/57 03/7B 05/1F 1 00,01 (Off , On)
PitchBend Range 01/34 02/58 03/7C 05/20 1 00-11
Modulation Wheel On/Off 01/31 02/55 03/79 05/1D 1 00,01 (Off , On)
Modulation Wheel Assign 01/32 02/56 03/7A 05/1E 1 00-11*
SW1 On/Off 01/35 02/59 03/7D 05/21 1 00,01 (Off , On)
SW1 Assign 00/3A 1 0-9*
SW2 On/Off 01/36 02/5A 03/7E 05/22 1 00,01 (Off , On)
SW2 Assign 00/3B 1 0-9*
Right Pedal On/Off 01/2D 02/51 03/75 05/19 1 00,01 (Off , On)
Right Pedal Assign 00/2F 1 00-11*
Center Pedal On/Off 01/2E 02/52 03/76 05/1A 1 00,01(Off ,On)
Center Pedal Assign 00/30 1 00-11*
Left Pedal On/Off 01/2F 02/53 03/77 05/1B 1 00,01 (Off , On)
Left Pedal Assign 00/31 1 00-11*
EXP Pedal On/Off 01/30 02/54 03/78 05/1C 1 00,01 (Off , On)
EXP Pedal Assign 00/32 1 00-11*
7. KnobAsgn KnobA Assign (1/2) 01/60 02/04 04/28 05/4C 2 see 3.6: Internal Section's Assignable Knob Data
KnobB Assign (1/2) 01/61 02/05 04/29 05/4D 2 see 3.6: Internal Section's Assignable Knob Data
KnobC Assign (1/2) 01/62 02/06 04/2A 05/4E 2 see 3.6: Internal Section's Assignable Knob Data
KnobD Assign (1/2) 01/63 02/07 04/2B 05/4F 2 see 3.6: Internal Section's Assignable Knob Data
KnobA Assign (2/2) 01/64 02/08 04/2C 05/50 2 see 3.6: Internal Section's Assignable Knob Data
KnobB Assign (2/2) 01/65 02/09 04/2D 05/51 2 see 3.6: Internal Section's Assignable Knob Data
KnobC Assign (2/2) 01/66 02/0A 04/2E 05/52 2 see 3.6: Internal Section's Assignable Knob Data
KnobD Assign (2/2) 01/67 02/0B 04/2F 05/53 2 see 3.6: Internal Section's Assignable Knob Data
8. VirtTech Voicing 00/65 02/09 03/2D 04/51 1 00-05 (Normal, Mellow1, Mellow2, Dynamic, Bright1, Bright2)
Stereo Width 00/66 02/0A 03/2E 04/52 1 00-7F
String Resonance 00/67 02/0B 03/2F 04/53 1 00,01-0A (Off , 1-10)
Damper Resonance 00/68 02/0C 03/30 04/54 1 00,01-0A (Off , 1-10)
KeyOff Eff ect 00/69 02/0D 03/31 04/55 1 00,01-0A (Off , 1-10)
Damper Noise 00/6A 02/0E 03/32 04/56 1 00,01-0A (Off , 1-10)
Hammer Delay 00/6B 02/0F 03/33 04/57 1 00,01-0A (Off , 1-10)
Fallback Noise 00/6C 02/10 03/34 04/58 1 00,01-0A (Off , 1-10)
Topboard 00/6E 02/12 03/36 04/5A 1 00-03 (Close, Open1~3 )
KeyOff Noise 00/6C 02/10 02/34 04/58 1 00,01-0A (Off , 1-10)
KeyOff Noise Delay 00/6D 02/11 02/35 04/59 1 00-7F
Key Click 01/5D - - - 1 0-7F
Wheel Noise 01/5E - - - 1 0-7F
* Pedal/Wheel assign: Mod., Pan., Exp., Damper, Soste., Soft, Reso., Cutoff , EFX1 Para1~10, EFX2 Para1~10
* SW Button assign: Oct.Layer, Rotary, Solo, Portament, Bend.Lock, Mod.Lock, CenterLock, Left Lock, EXP Lock, TW Control
Implementazione MIDI
