8
GB INSTRUCTION FOR THE INSTALLER
The operations indicated below must be followed by qualified personnel exclusively, in conformity
with the regulations in force.
The manufacturing firm refuses all responsibility for damages to people, animal or things,
resulting fron the failure to comply with such provisions.
INSTALLATION
The appliance is designed to be embedded into
heat-resistant pieces of forniture.
Make a hole in the top of the piece of forniture
with the dimension indicated in fig. 4at a distance
of at east 50 mm from the appliance border to the
adjacent walls.
Adhesive washer “S” slong the border of the top
bottom (fig.5)
Block it with the fastening hooks “C” (fig.6)
ELECTRICAL CONNECTIONS ( fig.7)
Before carryng out electrical connection be sure
that the characteristics of the electrical system
meet the specifications of the located at the
bottom of the work-top and the electrical system
is provided with effective ground in compliance
with the regulations and provision of the law in
force.
The ground is binding according to the law.
If the appliance is not provided with cable and/or
relative plug, apply a standardized plug to the
power supply cable.
If you wish a direct connection to the line , it is
necessary to interpose a single-pole switch, whit a
minimum opening between the contactsof 3 mm. ,
suitable for the indicated in the plate and in
conformity with the rules in force ( the
yellow/green ground cable should not be
interrupted by the swich).
ATTENTION
Should a built-in oven or any other appliance
producing heat be fitted directly under a glass
ceramic cook-top with Touch Control, it is
necessary isolate the hob whith a separator. The
bottom temperature must be low 60°C.
Disregard of this precaution could cause the
wrong working of the Touch Control system.
